Key features
- 4MP Video with High Dynamic Range (HDR)
- White Spotlight
- Onboard Recording with Smart View for continuous, local, encrypted recordings
- Video Analytics with People, Animal, and Vehicle Detection
- Perimeter Guard™ and Manually Triggered Warning Sounds for proactive deterrence
- Two-Way Audio
- Power over Ethernet
Specifications
| Recording Compression | H.264 |
| Image Sensor | 1/3”, 4MP, HDR |
| Lens | Focal length: 2.49 mm Aperture: F1.7 |
| Field of View | 129° Horizontal 68° Vertical 153° Diagonal |
| Max Resolution | 2688 x 1520 |
| Ethernet connection | 10/100 Mbps RJ-45 |
| Ingress Protection | IP66 |
| Dimensions (L x W x H) | 4.8 x 3.1 x 3.1 (12.2 x 7.8 x 7.8 cm) |
| IR Range | Up to ~49 ft (15 m) |
| Night Vision | IR Mode (grayscale), Spotlight Mode (color) |
| Operating Temperature | -58°F – 122°F (-50°C – 50°C) |
| Operating Humidity | <95% (non-condensing) RH |
| Input voltage | 802.3af Type 1 PoE or 12V – 1.5A DC power adapter (not included) |
| Power consumption Idle | 3.5W |
| Power consumption Day - IR Off | 3.75W |
| Power consumption Night - IR On | 7W |
| Power consumption Spotlight/Siren Activated | 10.5W |
| Power consumption Peak | 12W |
LED reference guide
| LED pattern | Description |
|---|---|
| Off | Power off |
| Solid green | Connected to Alarm.com |
| Blinking green | Local network connection |
| Blinking red | Power on, camera booting |
| Solid red | No local or internet connection |
| Blinking white | Bluetooth and Wi-Fi Access Point modes (press and hold the button for 3-6 seconds) |
| Blinking blue | WPS mode (press and hold button for 6-9 seconds) |
| Blinking yellow | Power cycling (press and hold button for 9-12 seconds) |
| Blinking red and green | Reverting to factory default settings (press and hold the button for 12-15 seconds) |
| Blinking green and blue | Firmware updating |
